22 t horizontal petrol log splitter with log lifter, 1 m splitting length (HS22331)

(5 customer reviews)

2.490.00

Includes 19% VAT
Available again from 16.08.2021.
Delivery Time: approx. 6-12 workdays

  • 22 t splitting force
  • 100 cm splitting length – 1m splitting length
  • Horizontal working
  • Wood diameter: max. 50 cm
  • Oil filter for a longer service life
  • Log lifter up to 80 kg load capacity

This log splitter is only available pre-assembled. The hydraulic oil HLP46 is included in the delivery. You only need to fill this in yourself. However, you would have to obtain the engine oil yourself in advance and also fill it up (approx. 0.6-1.1 liters). We recommend Briggs&Stratton 4-Stoken Engine Oil SAE30 for this.

In stock

+ -
Select delivery location


22 t horizontal petrol log splitter with log lifter, 1m gap length (HS22331)

With the HS22331 from HZC Power, you can split logs up to 1000 mm long with a splitting force of up to 22 tons. This puts the log splitter in first place in our range in terms of splitting length, so that really long logs can be split if required. Find out more now and buy your new log splitter.

The HS22331 log splitter can be operated horizontally. The two-handed operation ensures the necessary safety, e.g. the splitting wedge retracts automatically when the lever is released.

Wood splitter with petrol engine

The log splitter is equipped with a reliable Briggs&Stratton petrol engine. The engine is equipped with 12.88 Nm gross torque and 208cc.

Briggs&Stratton’s maintenance/repair service in selected partner garages provides uncomplicated assistance should problems arise with the powerful engine.

Lying log splitter

The HS22331 can be operated horizontally and can therefore be used very flexibly.

An oil filter for the hydraulic oil ensures an even longer service life for the log splitter. The machine has a trailer coupling so that it can be easily moved around the yard or within private grounds. However, the HS22331 is not road-legal. However, due to its handy dimensions, the log splitter can be easily transported on a trailer. Do you still have questions? Then please get in touch with us. Otherwise, buy your log splitter new from us

Angebot für Ihren Holzspalter

Bei HZC Power achten wir stets auf höchste Qualität, technisch einwandfreie Verarbeitung und eine robuste Konstruktion. Unsere Holzspalter erhalten Sie teilmontiert per Spedition. Eventuell muss das Hydrauliköl aufgefüllt werden - dieses liefern wir mit! Dabei bieten wir Ihnen einen Festpreis für den Versand der automatisch im Warenkorb generiert wird (zusätzliche Versandinformationen finden sie hier).

Gerne können Sie unsere Produkte nach Absprache auch in unserer Zentrale besichtigen oder kostenlos abholen.

Sollten Sie weitere Fragen zu den einzelnen Modellen haben dann melden Sie sich gerne bei unserem Kundenservice. Dieser berät Sie gerne weiter. Überzeugen Sie sich selbst von unserem Angebot und sichern Sie sich Ihren Holzspalter in bester Qualität zum besten Preis bei HZC Power.

Technical data

Manufacturer: HZC Power GmbH
Model: HS22331
Splitting force: 22 t
Gap length: max. 1000 mm
Cycle: 24 s
Hydraulic oil capacity: 23,5 l (HLP46)
Product weight: 325 kg
Shipping weight: 360 kg
Special features: Trailer coupling, turntable & support arms
Working positions: Horizontal
Operation: 2-handedEngine

Engine

Engine: Briggs & Stratton 6.5 hp petrol engine, XR950
Model number: 130G
Engine technology: Single cylinder, 4-stroke, air-cooled, OHV (overhead valves)
Displacement: 208 cc
Cylinder: cylinder with cast iron sleeve
Drill hole: 68,3 mm
Bar: 55,9 mm
Fuel tank capacity: 3.1 l
Oil capacity: 0.6 l
Weight: 16 kg
Dimensions: 321x376x346 mm

Video about wood splitter assembly

Montage von einem 40 t liegend Holzspalter mit Benzinmotor & Stammheber (HS40335) von HZC Power

Rund um das Thema Holzspalter

Spaltkreuze für Holzspalter

Durch ein Spaltkreuz wird das Holz nicht nur halbiert, sondern direkt geviertelt. So erreicht man schneller die notwendige Größe der geschnittenen Holzstücke für den ein oder anderen Kamin (mehr lesen).

Spaltkraft beim Holzspalter

Was sagt eigentlich die Spaltkraft eines Holzspalters aus und wieviel Spaltkraft benötige ich für meinen Holzspalter? Welche Faktoren beeinflussen überhaupt die Spaltkraft? (mehr lesen)

Wieso einen Holzspalter kaufen?

Schauen Sie auch gerne in unserem HZC Power Magazin vorbei, dort erfahren Sie noch mehr zum Thema Holzspalter und erfahren noch mehr Tipps & Tricks. Informieren Sie sich z. B. hier über die Vorteile eines Kaufs von einem unserer Holzspalter.

Weight 360 kg

Based on 5 reviews

5.00 Overall
100%
0%
0%
0%
0%

Show reviews in all languages (12)

Add a review

Your email address will not be published. Required fields are marked *

5 reviews for 22 t horizontal petrol log splitter with log lifter, 1 m splitting length (HS22331)

  1. Willi

    Really cool
    Super, can not complain!
    Have me subsequently but still ordered a turntable to it, was only unsure but am now happy about it!

  2. Julien M

    good
    all good, can only recommend

  3. Michael Vogt

    Top splitter
    I was looking for a splitter with trailer device that you can operate lying and standing, it was important to me when buying that the hydraulic cylinder can be retracted, that the splitter is now not quite so large. Retracted the splitter has a total length of about 2.20 m extended about 2.60 m. The splitter was grinded in almost ready to use condition, only the drawbar had to be screwed on, check oil quantities and fill in gasoline and off we go. On the whole, the splitter is solidly built, the engine is sufficient for the power handling and operation are also very easy and understandable. What I miss on the splitter or would still wish, would be holding brackets when standing splitting of long logs “back friendly” would be, because you can lean the logs then. But that would be no problem for me, this to plug off itself. All in all, I am very satisfied with the splitter and do not regret the purchase. After about 35 FM oak logs up to about 50 cm in diameter, I am very satisfied with the speed and the Spaltgebniss (with splitting wedge).
    The only minor drawback is the support wheel. when turning up and down, the ball handle loosens again and again. here I have remedied the situation by changing one of the conventional support wheels the handle with a self-locking nut.

    Conclusion:

    I can only recommend the splitter it is worth the money and with the accessories such as splitting wedge and turntable, the whole thing is a fine thing. Now we hope that we will have long joy with the splitter.

  4. S. Mönch

    Perfect and inexpensive
    The splitter splits my wood perfectly, without problems, even for a long time. The price is fully in order and I am very satisfied.
    Thanks also to the nice contact for the advice.

  5. V. Michael

    Top splitter at a fair price
    Really great splitter. Can only recommend it.
    Runs quietly is easy to use and economical in consumption. What I particularly like is that the cylinder can be inserted so that the splitter has a total length of about 2.20 meters. Others in this price range do not have this.
    That was also my clear purchase decision.
